SPEC: ANSI, DIN, DRAWING, SAMPLE
HEAD: BUGLE HEAD, DOUBLE BUGLE HEAD, TRIM HEAD WITH NIBS UNDER HEAD, MODIFIED TRUSS HEAD, PAN FRAMING HEAD, SPECIAL PAN HEAD
RECESS: SQUARE, PHILIPS
THREAD TYPE: TYPE “S”, COARSE THREAD, HI-LO, TWINFAST THREAD
SIZE:
3.5*25~3.5*55
3.9*19~3.9*55
4.2*13~4.2*45
4.8*50~4.8*140
MATERIAL: C1022, C1018
SURFACE FINISHED: ZINC PLATED, YELLOW ZINC, GREY PHOSPHATED, BLACK PHOSPHATED, TUFCOTE KAITEX COATING, RUSPERT-SILVER
SPEC: DRAWING, SAMPLE
HEAD: DOUBLE FLAT HEAD, FLAT HEAD, PAN HEAD, OVAL HEAD, FLANGE HEAD, TRIM HEAD WITH NIBS UNDER HEAD
RECESS: POZI, TORX, POZIDRIV WITH HOLE
THREAD TYPE: TYPE 17, WITH FLUTE
SIZE:
3.0*10~3.0*45
3.5*15~3.5*50
4.0*20~4.0*50
4.5*25~4.5*75
5.0*16~120
6.0*20~200
MATERIAL: C1022, SS302, SS305
SURFACE FINISHED:
ZINC PLATED, YELLOW ZINC, GREY PHOSPHATED, BLACK PHOSPHATED, TUFCOTE KAITEX COATING, RUSPERT-SILVER
SPEC: ANSI, DIN, DRAWING, SAMPLE
HEAD: BUGLE HEAD, FLAT HEAD, PAN HEAD, HEX WASHER HEAD, OVAL HEAD, MODIFIED TRUSS HEAD, TRIM HEAD, FLAT WAFER HEAD, PAN FRAMING HEAD, PAN WAFER HEAD
RECESS: PHILIPS, SQUARE DRIVE, TORX DRIVE
THREAD TYPE: TYPE AB、TYPE A、MACHINE THREAD、SHANKSLOT
SIZE:
#6~#14DIA
3.5mm ~ 6.3mm DIA
#12-11*25~#12-11*65
#12-14*35~#12-14*65
5.5*25 ~ 5.5*38 #3 POINT
6.3*19 ~ 6.3*50 #3 POINT
DRILLING POINT: #1, #2, #3, #4, #5
MATERIAL: C1018, C1022, SS302, SS304, , SS316, SS410
SURFACE FINISHED: ZINC PLATED, YELLOW ZINC, GREY PHOSPHATED, BLACK PHOSPHATED, TUFCOTE KAITEX COATING, RUSPERT-SILVER
SPEC: DIN, DRAWING, SAMPLE
HEAD: FLANGE HWH HEAD, HEX WASHER HEAD
THREAD TYPE：TYPE AB, TYPE A, MACHINE THREAD, TYPE 17, SHANKSLOT
MATERIAL: C1018, C1022
SURFACE FINISHED: ZINC PLATED, YELLOW ZINC, GREY PHOSPHATED, BLACK PHOSPHATED, TUFCOTE KAITEX COATING, RUSPERT-SILVER
SPEC: DIN, DRAWING, SAMPLE
HEAD: FLAT HEAD, PAN HEAD, OVAL HEAD, TRUSS HEAD, MODIFIED TROSS HEAD, ROUND WASHER HEAD
RECESS: PHILIPS SQUARE, QUAD REX (COMB、SQ+PHLIPS), SQUARE+SLOTED
THREAD TYPE: COARSE THREAD, TWIN FAST THREAD, HI-LO THREAD, BUTTRESS THREAD
SIZE: #4~#14
LENGTH: 1/2”~4"
MATERIAL: C1018, C1022, SS302
SURFACE FINISHED: ZINC PLATED, YELLOW ZINC, GREY PHOSPHATED, BLACK PHOSPHATED, TUFCOTE KAITEX COATING, RUSPERT-SILVER
SPEC: ANSI, DIN, DRAWING, SAMPLE
HEAD: FLAT HEAD, PAN HEAD, TRUSS HEAD, OVAL HEAD, HEX WASHER HEAD, WAFER HEAD
RECESS: PHILIPS SQUARE, SLOTE PHILIPS SQUARE, POZI
THREAD TYPE: TYPE AB, TYPE BZ, TYPE A, TYPE D, TYPE 1, TYPE 17, TYPE 25, TYPE 23, TYPE "F", DOG POINT,
FORM C, FORM F
SIZE: DIA #4~#14(2.9~6.3MM)
MATERIAL: C1022, SS302, SS410
SURFACE FINISHED: ZINC PLATED, YELLOW ZINC, GREY PHOSPHATED, BLACK PHOSPHATED, TUFCOTE KAITEX COATING, RUSPERT-SILVER
